The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh sizes which is mainly for road construction, mountain protection, river protection and so on. The possible raw materials are galvanized wire or PVC coated wire. We can manufacture gabion machine according to customer request.
Mesh Size(mm) | Max. Netting(mm) | Max. Dia of Weaving wire(mm) | Max.Dia of Bordering wire(mm) | Max.Weaving- | Power | Exact Manufacturing Speed | Exterior Size | Weight | |
Mesh Hole netting | Meter | L×W×H | |||||||
80×100 | 4700 | 3.2 | 4.0 | 3/5 | 22 | 42 | 170 | 7.2×1.4×2.4 | 15 |
5700 | 3.2 | 4.0 | 3/5 | 30 | 42 | 170 | 8.2×1.4×2.4 | 16 | |
100×120 | 4700 | 3.5 | 4.0 | 3/5 | 22 | 42 | 195 | 7.2×1.4×2.4 | 15 |
5700 | 3.5 | 4.0 | 3/5 | 30 | 42 | 195 | 8.2×1.4×2.4 | 16 | |
60×80 | 4700 | 3.5 | 4.0 | 3/5 | 22 | 42 | 150 | 7.2×1.4×2.4 | 15 |
5700 | 3.5 | 4.0 | 3/5 | 30 | 42 | 150 | 8.2×1.4×2.4 | 16 | |
Mesh Size's range from 50*70 mm To 176*200 mm;
Machine width: 3700/4700/5700mm;
We can design the machine to produce the mesh size according to customer's request. But the mesh size should in the range of 50*70 mm To 176*200 mm;
Range of galvanized wire:2.0mm~4.0mm(for different mesh size please find the parameter in the specification);
Range of PVC coating galvanized wire: ≤5.0mm;
Our motor adopt Frequency Motor;
All the bush in gabion mesh machine is real copper, with longer life time
Guarantee and After-Service
Guarantee time: one year since machine was at buyer' factory within 12 months against B/L date
Within guarantee time, if any components are broken under normal condition, we can change for free.
We can send our best technician to buyer's factory for installation, debugging and training.
Complete installation instructions, circuit diagram, manual operations and machine layout.
Technical support by e-mail.
